This is the Align RCE-BL100A ESC, for use with 500-550 sized Helicopters.
Brand new ESC controller is built-in with BEC voltage setting, allow for continuous current 10A and more, also support surge current support up to 25A, much powerful and precision. Moreover, it utilize with high quality 32 bit M4 ARM processor and superior governor performance, support the best flight performance for all pilots in every level.
1. Superior 32 bits M4 ARM Processor
2. High Quality MOSFET
3. Adjustable Voltage and 10A Large BEC
4. Excellent Governor Function
5. Cool ESC Temperature Keep it Much Reliable
6. Support ASBOX Multifunction Programmer Set Up
Specifications:
Main Applications: 500-550 Class Helis
Governor: Internal
Built-in BEC: Yes; Switch Mode: 5V-8V, 10A
Continuous Current: 100A
Cell Count: 3-6S
Case: Aluminum Alloy Shell
Programming: LCD Program Box
Peak Current: 170A
Weight: 138g
Dimensions: 84.3x38.2x20.4mm
DEO Technology: Yes
Spark-Proof: Yes
Brand new 730MX motor is especially designed for power upgraded T-REX 550X, normally found in 700 class high spec helicopter, that enthusiasts can clearly feel the dramatic increase in power and torque, while taking advantage of its higher efficiency, lower current and temperature benefits.
●The 730MX(850KV) motor armature had a special balance adjust to improve the serious shaking problem that other tiny motors have.
●Maintenance free, high torque, high efficiency, stable and quiet.
●High-speed ball bearings, powerful magnetic outrunner rotor.
●Input voltage: 6S
●Max continuous current: 115A/195A(5sec)
●Max output power: 2550W/4330W(5sec)
●KV value: 960KV
●Stator Dimension:4230
●Stator Arms: 12
●Magnet Poles: 8
●Dimension: 6x52x89.1mm
●Weight: 380g
